yes something like that he may need to copy the gracenote files to the folder on the sd card he is using also i experienced this before.
MIB2/MHI2 Harman High - MHI2_ER_SEG11_P4709_1_MU1447 - AIO FW update & ifs-root Patch (ASI, CarPlay, Android Auto, Map Update)
- Thread starter MIB-Wiki
- Start date
You'd have to make sure the metacheck added up if you started to modify the 1447aio software. Whilst the encryption sla signature is avoided. The check sums must still work out.
Its not editing the script the gracenote folder has nothing in it from memory, i had to put the database in there and run the update again for it to finish the update properly and not skip anything.
I found the toolbox for the high version quite buggy to use had to use more than one version to make things work. The std mib2 is a breeze
Right. I don't think it's a big loss if it works without Gracenotes. Gracenotes is just cover art that you can load yourself.
Yes you can actually just skip gracenote but it sounds like the patch has changed something else like a varient or region or something. I had strange results if LTE was disabled for some unknown reason.
Also check branding is still set as seat
Last edited:
I no longer have a mib2 high unit to check. But as i said you need to go back into the toolbox and check some settings for varient etc.
Navigation stuck on initialising 11% after Carplay activation. · Mr-MIBonk M.I.B._More-Incredible-Bash · Discussion #523
I have no idea what has caused this as I have done this procedure before with success... I tried to update maps to the newest version to see if it would budge but I just get NavDB_Check timeout. Am...
github.com
Maybe serach the error it would have happend to someone else.
I don't think he's used the tool box yet. I suggest via swdl install a non modded version of the firmware then mod it with the toolbox. It's the modded version of 1447AIO that has failed. Probably someone has loaded up a poor version onto mibsolution.one where there was one that was fine before. That's what I suspect happened. Swdl on the mib2 high will allow you to re install firmware whilst the normal front screen won't.I no longer have a mib2 high unit to check. But as i said you need to go back into the toolbox and check some settings for varient etc.
Navigation stuck on initialising 11% after Carplay activation. · Mr-MIBonk M.I.B._More-Incredible-Bash · Discussion #523
I have no idea what has caused this as I have done this procedure before with success... I tried to update maps to the newest version to see if it would budge but I just get NavDB_Check timeout. Am...
Maybe serach the error it would have happend to someone else.
I believe that map memory will be empty after 1447AIO so you have to load up the maps. N/A may just be saying the memory map store is empty. That's where I load the maps in via swdl with the door open to keep the power on. It will moan fairly quickly if it's not taking the maps. That's worth checking if that hasn't been done. Assuming the maps are presented correctly. 7zip unzipped, no mac involved etc.
Failing that try an unmodded version of the firmware and the mib2 high Mr bonk toolkit. 1447 original. Unfortunately I think the mib2 high firmware experts have flown. I use swdl on the map updates since I like to see the maps being read in and progress. But that back end tool covers all aspects of how the mib2 high units assorted memory areas are accessed for updates. The hackers have bypassed the signature protection which is how 1447aio was constructed which is fine if they got it right. But will trip out if they haven't. Mr bonk toolkit is the alternative to mod the unit from an original firmware.
I do have a link when I used the tool which gets a bit heady.
Bones of using mib2 tool is here:
SW update for MIB2 infotainment system?
Working towards it... more of a cloudy day tomorrow so good for sitting in the car on it ;). It was Chillout's bragging on Drive and Jose on the Spanish board that alerted me to the 192 solution. Jose says MIB Tools wasn't used. Used a retro-fitter. Taking the DIY route but @jpmedia has offered...
www.seatcupra.net
Basically it's menu driven from the green menu. It's preset up with all the FeCs you need but you can add extra if required. It's one of these things you only use once and when it works. Job done.
I thought the aio version was for hacked units only ? He should have just used the official one in that case. I assumed the unit was a retrofit.I don't think he's used the tool box yet. I suggest via swdl install a non modded version of the firmware then mod it with the toolbox. It's the modded version of 1447AIO that has failed. Probably someone has loaded up a poor version onto mibsolution.one where there was one that was fine before. That's what I suspect happened. Swdl on the mib2 high will allow you to re install firmware whilst the normal front screen won't.
I believe that map memory will be empty after 1447AIO so you have to load up the maps. N/A may just be saying the memory map store is empty. That's where I load the maps in via swdl with the door open to keep the power on. It will moan fairly quickly if it's not taking the maps. That's worth checking if that hasn't been done. Assuming the maps are presented correctly. 7zip unzipped, no mac involved etc.
Failing that try an unmodded version of the firmware and the mib2 high Mr bonk toolkit. 1447 original. Unfortunately I think the mib2 high firmware experts have flown. I use swdl on the map updates since I like to see the maps being read in and progress. But that back end tool covers all aspects of how the mib2 high units assorted memory areas are accessed for updates. The hackers have bypassed the signature protection which is how 1447aio was constructed which is fine if they got it right. But will trip out if they haven't. Mr bonk toolkit is the alternative to mod the unit from an original firmware.
I do have a link when I used the tool which gets a bit heady.
Bones of using mib2 tool is here:
SW update for MIB2 infotainment system?
Working towards it... more of a cloudy day tomorrow so good for sitting in the car on it ;). It was Chillout's bragging on Drive and Jose on the Spanish board that alerted me to the 192 solution. Jose says MIB Tools wasn't used. Used a retro-fitter. Taking the DIY route but @jpmedia has offered...
Basically it's menu driven from the green menu. It's preset up with all the FeCs you need but you can add extra if required. It's one of these things you only use once and when it works. Job done.
No it works on any Seat mib2 high unit. The people behind it took the final 1447 firmware then using the method to evade the firmware signature check modified the firmware to add all all the FeCs you'd ever need. Update Gracenotes beyond the final release on the official firmware.
There have been good experiences on quite old mib2 highs. It does not suffer from the train issue of jumping trains as the mib2 standard. It might delete the map memory in the process. I seem to recall that people had to reload the maps. Normally on firmware updates you don't.
The original 1447 firmware had some teething problem when installed you had to change the screen to "copper" before installation else it came up blank. Then you recoded that to get it to show. But better change that before you started to that Cupra boy racer diamond background.
The German Digital Eliteboard had threads on the original 1447 firmware and this issue. So 1447AIO sorted that out plus giving you life long navigation FeCs plus unlocking performance and off road screens. Hence the all in one designation. It avoided the use of the mib2 high Mr Bonk toolkit for the FeC work.
